As you may be aware, the spectacular Eminence N314 X is not currently available. Since we are helpless SpeakerAddicts here, we couldn't allow this terrible injustice!!!
As a result, we purchased a number of N314T-16 drivers from Eminence as well as all the N314X-8 diaphragms they had but 1. We are swapping the diaphragms for you so the amazing performance of the N314X can still be within the grasp of a lucky few while they are out of stock.
What's the difference you ask? The sticker on the side will say N314T-16 and the back cap won't have the N314X logo. Other than that, these will perform exactly as the N314X-8
Get them while you can, we don't have many
Here's the info from Eminence:
Audiophiles, prepare yourself for goosebumps. Eminence is revolutionizing the Pro Audio industry again. Meet the latest in high-frequency driver technology, the N314X-8. Utilizing an advanced new thin-ply carbon material, combined with the latest FEA techniques, the N314X-8 delivers Beryllium-like high-frequency extension with robustness unrivaled by any dome material. High speed of sound and acoustical figure of merit make this material a no-brainer. Couple that with unprecedented reliability compared to metal domes, and realize there is no better value in the world.
The 1.4 in. exit N314X-8 sets a new standard in compression drivers from Eminence. Featuring a 3 in. voice coil and a lightweight neodymium ring magnet with a copper shorting ring, the N314X-16 offers an ultra-clean sound and low crossover point.
| SPECIFICATION | |
| Throat Size | 1.4", 35.6mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 6.6 ohm @ 3.7 kHz |
| Power Rating** | 150 W (AES) |
| Resonance | .494kHz |
| Usable Frequency Range | 500Hz-20kHz |
| Recommended Crossover | 800 Hz / 12 DbkHz |
| Sensitivity*** | 110.5 |
| Magnet Material | Neodymium |
| Magnet Weight | 11oz, .31kg |
| Voice Coil Diameter | 3" / 76.2mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | TeXtreme® |
| DC Resistance (Re) | 4.8 |
| MOUNTING INFORMATION | |
| Overall Diameter | 5.72", 145.3mm |
| Driver Volume Displaced | 0.0234 cu.ft., 0.66 liters |
| Depth | 2.53", 64.3mm |
| Weight | 5.1 lbs, 2.3 kg |
| Mounting Thread | N/A |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4 in. 101.6 mm |
