| SPECIFICATION |
| Nominal Basket Diameter |
10", 254 mm |
| Nominal Impedance* |
8 Ω |
| Power Rating* |
| Program Power |
N/A |
| Watts |
75 W |
| Resonance |
105 Hz |
| Usable Frequency Range |
80 Hz - 4.5 kHz |
| Sensitivity* |
98.8 dB |
| Magnet Weight |
20 oz. |
| Gap Height |
0.312", 7.9 mm |
| Voice Coil Diameter |
1.5", 38 mm |
| THIELE & SMALL PARAMETERS |
| Resonant Frequency (fs) |
105 Hz |
| DC Resistance (Re) |
7.59 Ω |
| Coil Inductance (Le) |
0.37m H |
| Mechanical Q (Qms) |
13.27 |
| Electromagnetic Q (Qes) |
1.05 |
| Total Q (Qts) |
0.98 |
| Compliance Equivalent Volume (Vas) |
27 liters / 0.95 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) |
0 cc |
| Mechanical Compliance of Suspension (Cms) |
0.14 mm/N |
| BL Product (BL) |
8.8 T-M |
| Diaphragm Mass Inc. Airload (MMs) |
16 grams |
| Efficiency Bandwidth Product (EBP) |
100 |
| Maximum Linear Excursion (Xmax) |
0 mm |
| Surface Area of Cone (Sd) |
366.1 cm2 |
| Maximum Mechanical Limit (Xlim) |
N/A |
| MOUNTING INFORMATION |
| Recommended Enclosure Volume |
| Sealed |
Acceptable |
| Vented |
Acceptable |
| Driver Volume Displaced |
0.034 cu.ft. / 0.95 liters |
| Overall Diameter |
10.11", 256.8 mm |
| Baffle Hole Diameter |
9.13", 231.9 mm |
| Front Sealing Gasket |
Yes |
| Rear Sealing Gasket |
Yes |
| Mounting Holes Diameter |
0.23", 5.8mm |
| Mounting Holes B.C.D. |
9.6", 243.8mm |
| Depth |
4.2", 106.7 mm |
| Net Weight |
4.5 lbs, 2.04 kg |
| Shipping Weight |
6.4 lbs, 2.9 kgs |
| MATERIALS OF CONSTRUCTION |
| Coil Construction |
Copper voice coil |
| Coil Former |
Polyimide former |
| Magnet Composition |
Ferrite magnet |
| Core Details |
Non-vented core |
| |
|
| Basket Materials |
Pressed steel basket |
| Cone Composition |
Paper cone |
| Cone Edge Composition |
Paper cone edge |
| Dust Cap Composition |
Zurette dust cap |
